PFC Membrane Switch Panel LED Light BSD-5010-R7 Series – Premium Interface Solution for Medical Equipment
LEDs：
LEDs are the most popular and economical method for keyboard backlighting. LEDs are most commonly used to backlight keys, icons and symbols. LEDs are also typically used as indicator lights.
Light Guide Film ：
Light Guide Film is designed to evenly distribute light from top or side firing LEDs, providing bright, uniformed illumination.
Electroluminescence：
EL is applied on a very thin layer between the graphic overlay and the circuit. EL uses a printable ink deposit to illuminate the switch and provide a uniformed illuminati
Fiber Optics：
Fiber Optics provide a flexible back lighting layer that can be incorporated between the graphic overlay and the circuit layer allowing the entire surface area of the membrane switch to be evenly backlit.
The BSD-5010-R7 Series is a high-performance PFC (Polyester Film Capacitive) membrane switch panel with integrated LED backlighting, designed for precision medical machinery and industrial control systems. Engineered for durability and reliability, this panel features a tactile responsive interface, ensuring smooth operation in critical environments. The anti-glare, chemical-resistant polyester overlay provides long-term resistance to abrasion, disinfectants, and harsh cleaning agents, making it ideal for medical and laboratory equipment.
With customizable LED backlighting (multicolor options available), the panel ensures optimal visibility in low-light conditions, enhancing user efficiency. The IP67-rated sealing protects against dust, moisture, and contaminants, while the embedded ESD shielding prevents electrostatic interference. Compatible with PCB and flex circuit integration, the BSD-5010-R7 supports custom graphic overlays, embossing, and backlight dimming control.
Ideal for medical devices, diagnostic machines, and industrial control panels, this membrane switch panel combines ergonomic design, high sensitivity, and extended lifespan (1M+ cycles). Choose the BSD-5010-R7 Series for a seamless, hygienic, and user-friendly interface solution.
Key Features:
PFC Membrane Technology
LED Backlight (Custom Colors)
IP67 Protection & ESD Shielding
Chemical & Abrasion Resistant
Medical & Industrial Grade
Optimize your device's interface with the BSD-5010-R7 Series – where precision meets durability.
| Specifications | Spes | Rated current | Contact resistance | Life cycles | Travel | Trip force | Request Samples |
| Membrane Switch Panel Led Light BSD-5010-R7 |  |
35VDC，100mA，1W | 10--500Ω | Flat type ≥5,000,000 Tactile type ≥1,000,000 | Flat type 0.1~0.5mm Tactile type 0.6~1.5mm | Flat type 60g~300g(2~100Z) Tactle type 150g--400g(6--140Z） |
